Overview

The HUX-60 series distribution box is a terminal power distribution device for installing modular electrical appliances with an integral multiple of 18mm in width. The box and panel are made of metal materials by bending and welding. The installation can be divided into concealed installation and open installation. The box is long with insulating base, grounding and neutral terminals and lifting guide rail, and the upper, lower and bottom are provided with inlet and outlet holes.

The HUX-60 series distribution box is suitable for installing electrical components with 18mm module width and guide rail card; the circuit principle is 380V/220V three-phase five-wire system. Simple control circuit of single-phase three-wire system.

Normal working conditions

Installation method

1.1 Flush mounted：Flush mounted on hollow wall

1.2 Surface mounted：Installed on a non-flammable wall

Ambient temperature: Limited temperature -25℃～+60℃

The highest temperature during the building process: +60℃
